MIMO1212SG

12x12 | digital matrix | DSP

Digital Matrixes | Reference: CMIMO1212SG



MIMO1212SG (MIMO1212 SINGLE) is an EclerNet digital audio device that keeps the heart and soul of the standard MIMO88, its main features and its audio quality, to become a simplified and cost-effective version (12x12) of this acclaimed digital matrix.

  • 12x12 digital matrix (not expandable)
  • Fully programmable and controllable via EclerNet software
  • Remotely controlled with UCPs (User Control Panels), when a UCP Server is in the system, compatible with the touchscreen WPNETTOUCH and third-party devices, such as computers, tablets, smartphones, etc.
  • TP-NET protocol compatible, for third-party control systems integration
  • DSP processing: signal generator, delays, full parametric EQ filters at inputs and outputs, inputs noise gate, level, mute, phase, vu-meters, outputs compressor / limiter, paging and ducking (priority & overriding), virtual and physical paging stations management, presets save & recovery, scheduled events triggering, etc.
  • FREQUENCY SHIFTER function to avoid acoustic feedback, available in 4 inputs
  • WPNET4KV and WPNET8K compatible control panels (using specific retro-compatible Firmware).

Applications

Retail   Education   Corporate   Hospitality

Accessories

WPaCNX-CBO

Remote Wall Connector
View

WPaCNX-JRCA

Remote Wall Connector
View

WPaH-AT100

Remote Wall Attenuator
View

WPaMIX-T

Remote Wall Micro-Mixer
View

WPaVOL

Remote Wall Volume Control
View

WPaVOL-J

Remote Wall Volume Control + Connector
View

WPaVOL-SR

Remote Wall Source and Volume Control
View

WPaVOL-SR-J

Remote Wall Volume Control and Source + Connector
View

WPNET4KV

EclerNet Wall Control Panel
View

WPNET8K

EclerNet Wall Control Panel
View
