CA120

2x60 WRMS | stereo | micro-amplifier | EQ

Ultra-Compact Amplifiers | Reference: CCA120,CCA120C

CA120Image 1


CA120 is a 2 x 60 WRMS @ 4 ohm stereo amplifier with a tiny size but amazing remote control features: serial RS-232 port, IR receiver and 0-10 VDC remote port. It's an ideal solution in those audiovisual applications which require integration with external control devices: education classrooms, meeting rooms, multimedia presentations, retail shops, etc.

  • 2 x 60 W RMS @ 4Ω amplifier
  • Universal external power supply
  • AUTO STANDBY function: in the absence of an audio signal the unit automatically goes into STANDBY mode, minimising power consumption
  • Lightweight, silent, high-performance amplifier (fan-free convection cooling)
  • Suitable for stereo and parallel (mono)
  • 1 switchable balanced mic / unbalanced line input, with high quality microphone preamplifier, phantom power supply, noise gate and “talkover” function or priority over the rest of input
  • 3 stereo lines (not balanced)
  • 2-band independent tone control (Bass, Treble) for the microphone / line 3 and line 1&2 input connection.
  • Auxiliary output for liaison with other amplifiers or external audio devices
  • Local control by digital rotary knob (“encoder”)
  • Remote control by infrared remote control
  • Remote control by WPmVOL or WPmVOL-SR (0-10 VDC) wall panel
  • RS-232 control port, compatible with EclerCOMM software (free) and control protocol CANET
  • MUTE port to silence the entire unit by closing external contact

Applications

Retail   Education   Corporate   Leisure
