VEO-XRI2L

4K Low Latency Over IP Video Extender

Video Distribution Over IP | Reference: CVEOXRI2L

VEO-XRI2LImage 1


VEO-XRI2L is a low latency 4K HDMI extenders over IP. They also provide optional fiber optic connection for extension of 4K signals up to 2Km. This over IP solution is widely suitable for all the applications that require low latency video extension such as real time application or KVM. An intuitive user panel with LEDs display allows to select the stream channel just out of the box, without the need of connecting a PC. The extenders can be power supplied both via PoE or via the included external PSU. Web browser interface, PC tools and third party control protocol are available for advanced settings and advanced control.

  • Support Video Wall composition (Max 8x8)
  • 4K UHD HDMI over IP/Fiber Extension
  • Support point-to-point, point-to-multipoint and multipoint-to-multipoint configurations
  • USB2.0 over IP extension for KVM
  • Support transmission distances up to 120m over single Cat.5e/6 cable
  • Support fiber optic extensions up to 60Km (Single Mode)
  • Support up to 4K@60Hz YUV 4:2:0 input and 4K@30Hz outputs
  • HDCP 2.2 / HDCP1.4 compliant
  • Support Bi-Directional Wide Band IR (38kHz-56kHz) Pass through
  • Support RS-232 pass through and Telnet control (EclerNet Manager and third party remote control compatible).
  • Include IR remote/ Frontal Panel control of Group ID channel, with LED display to show the Group ID in use
  • Support Dolby True HD, DTS-HD Master Audio formats
  • Support 3D video formats
  • SPDIF 5.1 and L/R analog stereo embedding and de-embedding
  • Easy installation over Gigabit IGMP compliant LAN Networks
  • The extenders can be powered with PoE or with the included external power supply
