SYSTEM
Effective Freq. Range
91 Hz-20 kHz (-10dB)
Coverage angle / Dispersion
107°x107° (HxV)
Power handling
300 W RMS / 1200 W Peak
Sensitivity
100 dB (1W/1m)
Maximum SPL
125 dB continuous / 131 dB peak
Power options (Hi Z Multi-tap)
100V: 200W / 100W / 50W / OFF and 8Ω
70V: 100W / 50W / 25W / OFF and 8Ω
70V: 100W / 50W / 25W / OFF and 8Ω
Recommended amplifier power
600 W RMS
